Airtac X-EPHF Connector - In-Line Swivel Elbow X-EPHF10M20
AirTAC X-EPHF Series Tandem Swivel Joint Specifications - X-EPHF10M20
- Model: X-EPHF10M20
- Type: Tandem swivel joint with male thread
- Thread specification: M20×1.5 (male)
- Material: Chrome-plated brass body + POM composite bushings
- Max working pressure: 1.0 MPa
- Temperature range: -20℃ to 80℃ (dry air)
- Installation torque: 8-12 N·m
- Swivel angle: ±5° axial misalignment compensation
- Weight: 185±5g
- Dimensions: 72mm(L) × 28mm(W) × 28mm(H)
- Surface treatment: Electroless nickel plating (3-5μm)
- Vibration resistance: ≤10 m/s² (15-2000 Hz)
- Leakage rate: <3×10⁻² Pa·m³/s under rated pressure
Dual-axis pivoting joint featuring anti-vibration lock nuts and precision-ground sealing surfaces. Engineered for multi-directional piping configurations requiring simultaneous angular compensation. The chrome-plated brass construction resists chemical corrosion in humid environments while maintaining smooth rotation through POM bushings.
- Multi-axis robotic arm end effectors
- CNC machine tool coolant line connections
- Rotary indexing table pneumatic systems
- Automated packaging line actuator clusters
- Semiconductor wafer handling equipment
Installation note:
Apply 320-400 grit abrasive paper to clean male threads before assembly.
Use backup wrench on hex flats during tightening to prevent bushing deformation.
Maximum recommended rotation speed: 30 RPM.
| Property | Property Value |
|---|---|
| sku | X-EPHF10M20 |
