Airtac X-EPM Bulkhead Straight Connector X-EPM4
AirTAC X-EPM4 Bulkhead Straight Fitting Technical Details
- Model: X-EPM4
- Type: Bulkhead through fitting (panel-mounted)
- Thread standard: PT1/8, NPT1/8, G1/8 (customizable)
- Material: Nickel-plated brass body
- Seal material: NBR/FKM (optional)
- Operating pressure: 0.05-1.5 MPa
- Temperature range: -5℃ to 80℃
- Port configuration: Dual M5 threaded ports + bulkhead passthrough
- Panel thickness compatibility: 1-5mm
- Torque resistance: ≤3 N·m
- Weight: 50g ±2g
- Dimensions: 30mm(L) × 20mm(W) × 15mm(H)
- Surface roughness: Ra ≤3.2μm
- Pressure drop: ≤0.02 MPa @ 0.7 MPa
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certification: RoHS compliant
High-density panel connector featuring leak-proof design with dual O-ring seals (axial and radial). The through-body structure enables multi-directional piping layouts while maintaining compact dimensions. Anodized finish prevents galvanic corrosion when used with aluminum panels. Compatible with pneumatic tubing OD 4mm (1/8").
- Modular pneumatic control cabinets
- Robotic arm junction interfaces
- CNC machine tool manifold blocks
- Laboratory equipment pressure distribution
- Mobile hydraulic power units
- Semiconductor fab gas panels
Mounting guidance:
Use 4mm hex key for installation. Apply 1.2-1.5 N·m torque during assembly.
For vertical panel mounting, orient identification marks upward. Apply pipe sealant to male threads only.
| Property | Property Value |
|---|---|
| sku | X-EPM4 |
