Airtac X-EPY Connector - Y Type Tee X-EPY12
AirTAC X-EPY12 Y-Type Tee Fitting Technical Details
- Model: X-EPY12
- Type: Y-shaped pneumatic tee connector
- Body material: Nickel-plated brass (C3604)
- Thread standard: PT1/4 (BSPP) female threads
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Proof pressure: 1.5 MPa
- Burst pressure: ≥3.0 MPa
- Surface treatment: Electroless nickel plating (5-8μm)
- Weight: 48g ±2g
- Dimensions: 40mm(L) × 25mm(W) × 25mm(H)
- Tube compatibility: Ø12mm polyurethane/nylon tubing
Three-way flow divider with 120° branch angle design for balanced air distribution in compact pneumatic systems. Features corrosion-resistant construction with precision-machined threads (ISO 1179-1 compliant) and leak-proof O-ring seals. Internal flow path optimized for minimal pressure drop (ΔP ≤0.02MPa @ 0.5MPa).
- Modular pneumatic circuit branching in automation equipment
- Air tool manifold connections
- Packaging machine air distribution networks
- Medical device pneumatic control systems
- Robotic actuator supply line splitting
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads (not required for flange connections).
Tighten to 12-15N·m torque using backup wrench. Avoid overtightening which may
deform sealing surfaces. Inspect seals annually under continuous operation.
| Property | Property Value |
|---|---|
| sku | X-EPY12 |
