Airtac X-EPY Connector - Y Type Tee X-EPY16
$7.46
Regular price
$14.96
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-EPY16
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-EPY16 Y-Type Tee Fitting Technical Details
- Model: X-EPY16
- Type: Y-shaped triple union (equal-diameter branching)
- Material: Brass (nickel-plated surface)
- Seal material: NBR/FKM optional
- Port size: PT1/8 (G1/8 equivalent)
- Thread standard: ISO 228 (BSPP)
- Operating pressure: 0.1-1.0 MPa
- Proof pressure: 1.5 MPa
- Burst pressure: 3.0 MPa
- Temperature range: -20℃ to 80℃
- Weight: 24.5g ±0.5g
- Dimensions: 16mm (port-to-port) × 16mm (branch length) × 25mm (vertical height)
- Surface roughness: Ra ≤3.2μm
- Compatibility: Compressed air, inert gases (N2 recommended for FKM seals)
- Certification: RoHS compliant, ISO 9001 manufacturing
Precision-engineered Y-connector with triple leak-proof design, featuring radial sealing structure and 360° rotatable ports. Electroplated finish resists oxidation in humid environments. Tested for 50,000+ pressure cycles without deformation.
Ideal Applications:
- Pneumatic circuit branching in CNC machinery
- Sensor air supply distribution systems
- Vacuum line splitting for pick-and-place robots
- Medical device pneumatic manifolds
- Compressed air tool networks
Installation protocol:
Apply 2-3 wraps of PTFE tape clockwise on male threads.
Tighten to 1.2-1.5 N·m torque using backup wrench on hex base.
Avoid overtightening - sealant contact occurs at 270° rotation.
Fluid compatibility:
Not recommended for acetylene, chlorine, or oxygen-rich (>23%) environments.
For liquid applications, specify FKM seals and vertical downward orientation.
| Property | Property Value |
|---|---|
| sku | X-EPY16 |
