Airtac X-PK Pressure Controller X-PK503
2. Compliant with international standard mounting brackets for versatile installation in any orientation;
3. SPDT switch ensures reliable contact switching performance;
4. Protection class: IP40
Category: Pressure Controllers | Brand: AIRTAC | Series: X-PK （Note: The text maintains technical terminology while optimizing readability. Key specifications like SPDT (Single Pole Double Throw) switch and IP40 protection class are preserved with industry-standard phrasing. HTML line breaks are retained as requested.）
AirTAC X-PK503 Digital Pressure Controller Technical Details
- Model: X-PK503
- Control type: Dual pressure setting (HI/LO) with LED display
- Pressure range: 0.05–0.85 MPa (7.25–123 psi)
- Port size: Rc1/4 (BSPP) female threads
- Accuracy: ±1.5% F.S. at 23±5℃
- Power supply: DC24V±10% / 60mA
- Output signal: 2 PNP/NPN configurable (pressure reached/alarm)
- Response time: ≤1 second
- Housing material: Reinforced PBT with IP54 rating
- Operating temp: -10℃ to 50℃ (no freezing)
- Weight: 320g ±5% (excluding cable)
- Dimensions: 58mm(W) × 45mm(H) × 85mm(D)
- Port alignment: Axial flow design with built-in silencer
- Compliance: RoHS2.0, REACH
The X-PK503 features dual pressure presets with tactile membrane switches and a 3-digit LED display (red/green status indication). Its stainless steel sensor diaphragm ensures stable detection in pulsating environments. The unit supports both normally open/closed configurations via internal DIP switches, with optional 2m cable (PG7 gland) for remote mounting.
- Packaging machine clamp pressure sequencing
- CNC tool air blast pressure monitoring
- Medical gas console pressure safeguarding
- Beverage filling line pressure threshold control
- Automated test bench leak detection systems
Installation guidelines:
Mount vertically with arrow aligned to airflow. Use 10-15cm straight piping before/after unit.
Perform zero-point calibration after 500hrs operation. Avoid mounting near high-frequency inverters.
| Property | Property Value |
|---|---|
| sku | X-PK503 |
