Airtac 2-Way Solenoid Valve 2W050-10-E
2. Direct-acting normally closed 2-way 2-position solenoid valve featuring fast and precise switching;
3. Compact design with minimized footprint, lightweight construction, and tool-free installation;
4. Brass valve body with B-class thermal-rated coil. Standard FPM/FKM seals ensure compatibility with diverse media. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection, available in lead wire or DIN connector configurations.
Category: Solenoid Valves | Brand: AIRTAC | Series: 2W
AirTAC 2W050-10-E Solenoid Valve Technical Details
- Model: 2W050-10-E
- Type: 2-position 2-way normally closed (direct acting)
- Port size: PT1/8 (G1/8 optional)
- Thread standard: BSPP (parallel thread)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Proof pressure: 1.2 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC: 2.5W max | AC: 3.2VA max
- Response time: ≤15ms (excitation) | ≤20ms (de-excitation)
- Flow coefficient (Cv): 0.15
- Seal material: NBR (Nitrile rubber standard) | Optional FKM
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Ambient humidity: 35–95% RH (non-condensing)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Weight: 0.25 kg ±5%
- Dimensions: 50mm(L) × 30mm(W) × 60mm(H)
- Port connection torque: 2.0–3.0 N·m
High-response direct-operated valve featuring copper-wound solenoid coils with thermal protection. The compact body uses cold-forged brass construction with chrome-plated brass spool for smooth operation. Designed for applications requiring frequent switching cycles (up to 5Hz continuous operation). Requires 5μm filtered compressed air with lubrication not exceeding ISO VG32.
- Precision pneumatic clamping systems
- Beverage filling machine nozzle control
- Textile machinery air flow regulation
- Semiconductor wafer handling equipment
- Dental chair pneumatic systems
- Automated test bench instrumentation
Installation requirements:
Maintain vertical ±5° mounting orientation. Use vibration-resistant brackets
when installed on moving platforms. Allow 15-minute cool-down period after
continuous 2-hour high-frequency operation. Lubricant compatibility:
ISO VG32 turbine oil recommended.
| Property | Property Value |
|---|---|
| sku | 2W050-10-E |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC24V |
