Airtac 2-Way Solenoid Valve 2W050-15-E
2. Direct-acting normally closed 2-way 2-position solenoid valve featuring fast and precise switching;
3. Compact design with minimized footprint, lightweight construction, and tool-free installation;
4. Brass valve body with B-class thermal-rated coil. Standard FPM/FKM seals ensure compatibility with diverse media. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection, available in lead wire or DIN connector configurations.
Category: Solenoid Valves | Brand: AIRTAC | Series: 2W
AirTAC 2W050-15-E Solenoid Valve Technical Details
- Model: 2W050-15-E
- Type: 2-position 2-way direct acting (Normally Closed/Open selectable)
- Port size: PT1/4 (G1/4 optional)
- Thread standard: ISO228/ISO6149 compliant
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Proof pressure: 1.2 MPa max
- Voltage tolerance: ±10% (DC/AC)
- Voltage options:
- DC: 12V, 24V
- AC: 110V 50/60Hz, 220V 50Hz
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Response time: ≤15ms (excitation), ≤20ms (reset)
- Flow coefficient (Cv): 1.6
- Seal material: NBR (Nitrile) standard, optional FKM/Viton
- Ambient temperature: -5℃ to 80℃ (with intermittent 100℃ peaks)
- Protection rating: IP67 (coil), IP40 (valve body)
- Weight: 320g ±5% (with connector)
- Dimensions: 70mm(L) × 45mm(W) × 35mm(H) (excluding fittings)
High-flow compact solenoid valve with reinforced epoxy-coated coil for chemical resistance. Features manual override button and LED operation indicator (select models). Designed for 10 million cycle durability under rated conditions. Requires 5μm filtered air with ISO8573-1:2010 Class 4 purity (max 40mg/m³ oil content).
- CNC machine tool coolant control systems
- Plastic injection molding machine air circuits
- Beverage filling line pneumatic actuators
- Semiconductor wafer handling vacuum/pressure switching
- Railway brake system air control units
Installation protocol:
Mount in vibration <3.5G environments. Use flexible tubing connections
to prevent torque transmission. For horizontal mounting, orient coil
vertically upward. Allow 15-minute degaussing period after continuous
8-hour operation.
| Property | Property Value |
|---|---|
| sku | 2W050-15-E |
| Port Size | PT 1/2 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC24V |
