Airtac 2-Way Solenoid Valve 2W150-15-A
2. Direct-acting normally closed 2-way 2-position solenoid valve featuring fast and precise switching;
3. Compact design with minimized footprint, lightweight construction, and tool-free installation;
4. Brass valve body with B-class thermal-rated coil. Standard FPM/FKM seals ensure compatibility with diverse media. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection, available in lead wire or DIN connector configurations.
Category: Solenoid Valves | Brand: AIRTAC | Series: 2W
AirTAC 2W150-15-A Solenoid Valve Technical Details
- Model: 2W150-15-A
- Type: 2-position 2-way direct-acting (normally closed/open optional)
- Port size: G1/2" (BSPP thread)
- Operating pressure: 0.15–1.0 MPa
- Voltage variants: DC12V, DC24V, AC110V 50/60Hz, AC220V 50/60Hz
- Flow coefficient (Cv): 1.8
- Response time: ≤20ms (at rated voltage)
- Seal materials: NBR/FKM (standard/high temp options)
- Temperature range: -5℃ to 80℃ (extended to 120℃ with FKM seals)
- Weight: 520g ±5%
- Dimensions: 82mm(L) × 50mm(W) × 72mm(H)
- Power consumption: 2.2W (DC)/3.5VA (AC)
- Protection class: IP67 (dust/water resistant)
- Port alignment: Horizontal/vertical flow configuration
High-flow solenoid valve with reinforced brass body for industrial durability. Features manual override button for system diagnostics and low-hysteresis coil design. Compatible with compressed air (lubricated/non-lubricated) and neutral gases. Requires 5μm filtration (25μm max temporary use).
- Pneumatic cylinder control in assembly lines
- Dust collector pulse-jet valve systems
- Industrial washer fluid control
- HVAC damper actuators
- Semiconductor manufacturing equipment
- Beverage dispensing systems
Installation guidelines:
Mount with 30cm minimum upstream straight piping. Use anti-vibration
mounts in high-cycle applications (>1M operations/year). Lubricate
seals with ISO VG32 oil if using dry air supply.
- Max cycling rate: 5Hz (300 cycles/minute)
- Leakage: <10 bubbles/min (ISO 6952 test)
- Dielectric strength: 1,500V AC for 1min
- Insulation resistance: ≥100MΩ (500V DC megger)
| Property | Property Value |
|---|---|
| sku | 2W150-15-A |
| Port Size | PT 1/2 |
| Flow Aperture | <15mm> |
| Coil Voltage | AC220V |
