Airtac 2-Way Solenoid Valve 2W150-15-C
2. Direct-acting normally closed 2-way 2-position solenoid valve featuring fast and precise switching;
3. Compact design with minimized footprint, lightweight construction, and tool-free installation;
4. Brass valve body with B-class thermal-rated coil. Standard FPM/FKM seals ensure compatibility with diverse media. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection, available in lead wire or DIN connector configurations.
Category: Solenoid Valves | Brand: AIRTAC | Series: 2W
AirTAC 2W150-15-C Solenoid Valve Technical Details
- Model: 2W150-15-C
- Type: 2-position 2-way direct acting (bi-stable)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 850 l/min (Cv=1.2 at 0.5MPa)
- Response time: ≤15ms (at rated voltage)
- Seal material: High-grade HNBR rubber (FDA compliant)
- Temperature tolerance: -20℃ to 80℃ (with intermittent 100℃ peak)
- Power consumption: 2.2W (DC) / 3.5VA (AC)
- Electrical connection: DIN43650 Form C with LED indicator
- Protection class: IP67 (dust/water resistant)
- Weight: 180g ±5g (without connector)
- Dimensions: 50mm(L) × 25mm(W) × 60mm(H) (body only)
Industrial-grade 2/2-way valve featuring zero-pressure start capability and surge protection circuitry. The epoxy-encapsulated coil provides enhanced vibration resistance (up to 50m/s²) and electromagnetic shielding. Optimized flow path reduces pressure drop by 18% compared to previous generation models.
- Precision gas dosing in food packaging lines
- Vacuum generator control in PCB handling systems
- Coolant flow regulation for laser cutting machines
- Pneumatic gripper sequencing in robotic arms
- Cleanroom compatible semiconductor manufacturing tools
Installation protocol:
Requires 5μm filtration with automatic drain. For horizontal mounting,
use support bracket AKH-15M (sold separately). Maintain minimum 2mm
clearance from adjacent metallic surfaces to prevent inductive interference.
| Property | Property Value |
|---|---|
| sku | 2W150-15-C |
| Port Size | PT 1/2 |
| Flow Aperture | <15mm> |
| Coil Voltage | AC 110V |
