Airtac 2-Way Solenoid Valve 2W150-15-E
2. Direct-acting normally closed 2-way 2-position solenoid valve featuring fast and precise switching;
3. Compact design with minimized footprint, lightweight construction, and tool-free installation;
4. Brass valve body with B-class thermal-rated coil. Standard FPM/FKM seals ensure compatibility with diverse media. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection, available in lead wire or DIN connector configurations.
Category: Solenoid Valves | Brand: AIRTAC | Series: 2W
AirTAC 2W150-15-E Solenoid Valve Specifications
- Model: 2W150-15-E
- Type: 2-position 2-way direct acting (normally closed)
- Port size: PT1/2 (G1/2 optional)
- Thread standard: ISO228/1 (BSPP)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Proof pressure: 1.2 MPa max
- Voltage tolerance: ±10%
- Voltage options: DC12V/24V, AC110V/220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Flow coefficient (Cv): 3.2
- Weight: 520g ±3% (including coil)
- Dimensions: 90mm(L) × 50mm(W) × 60mm(H)
- Seal material: HNBR rubber (high nitrile)
- Temperature range: -20℃ to 80℃ (non-freezing)
- Power consumption: 4.5W (AC), 3.6W (DC)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port alignment: 30mm center spacing
High-flow solenoid valve with industrial-grade epoxy-coated aluminum body, designed for demanding pneumatic systems requiring rapid cycling. Features manual override button for system testing/diagnostics and surge protection circuitry. Requires 5μm filtered/dried air (ISO8573-1:2010 Class 3.4.2) with lubrication optional.
- Plastic injection molding machine actuators
- CNC pneumatic chuck control systems
- Industrial boiler combustion air regulation
- Automotive assembly line clamping devices
- Wastewater treatment aeration controls
Installation best practices:
Mount horizontally with flow arrow aligned. Use vibration-damping mounts
in high-shock environments. Replace seals every 50,000 cycles or 2 years
(whichever comes first) under continuous operation.
| Property | Property Value |
|---|---|
| sku | 2W150-15-E |
| Port Size | PT 1/2 |
| Flow Aperture | <15mm> |
| Coil Voltage | AC24V |
