Airtac 2-Way Solenoid Valve 2W200-20-A
2. Direct-acting normally closed 2-way 2-position solenoid valve featuring fast and precise switching;
3. Compact design with minimized footprint, lightweight construction, and tool-free installation;
4. Brass valve body with B-class thermal-rated coil. Standard FPM/FKM seals ensure compatibility with diverse media. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection, available in lead wire or DIN connector configurations.
Category: Solenoid Valves | Brand: AIRTAC | Series: 2W
AirTAC 2W200-20-A Solenoid Valve Technical Details
- Model: 2W200-20-A
- Type: 2/2-way direct-acting (normally closed or normally open options)
- Port connection: G1/4 (BSPP thread) with ISO 228 standard
- Effective area: 20mm²
- Operating pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (at 0.5MPa)
- Ambient temperature: -5℃ to 80℃ (no freezing)
- Fluid temperature: 0℃ to 60℃
- Seal material: Heat-resistant NBR (Nitrile)
- Body material: Die-cast aluminum alloy (anodized)
- Weight: 320g ±5% (without connector)
- Dimensions: 62mm(L) × 45mm(W) × 50mm(H) (excluding electrical connector)
- Protection class: IP67 (coil), IP40 (valve body)
- Flow capacity: CV 1.2 (Kv 1.05) at 0.6MPa
High-flow compact solenoid valve featuring dual-position control with manual override capability. The aluminum body with triple-layer epoxy coating ensures corrosion resistance in humid environments. Designed for 5 million cycle durability with ≤0.1L/min internal leakage (at 0.5MPa). Requires 5μm filtered compressed air with oil mist lubrication (ISO 8573-1 Class 3).
- Plastic injection molding machine ejectors
- CNC pneumatic tool changers
- Beverage filling line control systems
- Textile machinery tension control
- Semiconductor wafer handling robots
- Railway braking test benches
Maintenance protocol:
Perform monthly manual cycling during standby periods. Use locknuts with 15-20N·m torque
during installation. Avoid mounting near high-frequency inverters (maintain ≥50cm distance).
| Property | Property Value |
|---|---|
| sku | 2W200-20-A |
| Port Size | BSPT 3/4 |
| Flow Aperture | <20mm> |
| Coil Voltage | AC220V |
