Airtac 2KSH Fluid Control Valve 2KSH05010A
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH Fluid Control Valve 2KSH05010A Technical Details
- Model: 2KSH05010A
- Type: 2-position 5-way fluid control valve (pneumatic pilot operated)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.05–1.0 MPa
- Max flow rate: 750 L/min (Cv=1.2)
- Voltage options: DC12V, DC24V, AC110V, AC220V (coil specifications vary)
- Weight: 320g ±5% (including coil)
- Dimensions: 56mm(L) × 45mm(W) × 72mm(H)
- Body material: Anodized aluminum alloy (ISO/TC28/SC4)
- Seal material: FKM fluorocarbon rubber (Viton® equivalent)
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Response time: ≤15ms (at 0.5MPa)
- Port thread depth: 10mm (minimum engagement 7 threads)
- Protection rating: IP67 (when properly installed)
High-flow directional control valve with low power consumption design, featuring dual-pressure operation capability. The hardened aluminum body with corrosion-resistant coating ensures durability in humid environments. Requires 5μm filtration (40μm for emergency use) and lubricated air (ISO8573-1:2010 Class 4-4-3).
- Automated liquid dispensing systems (food-grade compatible)
- Coolant flow control in CNC machining centers
- Hydraulic pilot controls for heavy machinery
- Batch processing equipment in pharmaceutical manufacturing
- Water treatment plant valve sequencing
Installation guidelines:
Mount horizontally with arrow aligned to flow direction.
Use backup rings when handling high-viscosity fluids (>46 cSt).
Allow 15mm clearance below for manifold drainage.
| Property | Property Value |
|---|---|
| sku | 2KSH05010A |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC220V |
