Airtac 2KSH Fluid Control Valve 2KSH05010AI
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH Fluid Control Valve 2KSH05010AI Technical Specifications
- Model: 2KSH05010AI
- Type: 5/2-way single solenoid pilot-operated (monostable)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 750 L/min (ANR) at 0.5 MPa
- Response time: ≤15ms (exhaust to actuation)
- Weight: 320g ±5% (including coil)
- Dimensions: 56mm(L) × 40mm(W) × 78mm(H)
- Seal material: HNBR rubber (high nitrile compound)
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Protection rating: IP67 (coil protection)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with precision-machined aluminum body and dust-resistant plunger design. Features dual-color LED status indicator (red/green) and surge protection circuitry. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.4.3 air quality. Compatible with ISO 15407-1 compliant systems.
- Pneumatic cylinder sequencing in assembly lines
- Vacuum cup control in robotic pick-and-place systems
- Dual-pressure regulation for injection molding machines
- Compressed air distribution in semiconductor fabrication tools
- Automated paint spray control systems
Installation protocol:
Mount using M4 screws with vibration dampeners. Maintain minimum 20mm
clearance above exhaust ports. Perform manual override test before
commissioning. Lubricate with ISO VG32 turbine oil if used in
high-cycle applications (>500,000 operations/month).
| Property | Property Value |
|---|---|
| sku | 2KSH05010AI |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC220V |
