Airtac 2KSH Fluid Control Valve 2KSH05010B
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH05010B Fluid Control Valve Technical Details
- Model: 2KSH05010B
- Type: 5/2-way monostable solenoid valve (spring return)
- Port size: 1/4" BSPP (G1/4)
- Operating pressure: 0.2–1.0 MPa
- Max flow rate: 750 L/min (ANR)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response time: ≤15ms (excitation), ≤20ms (reset)
- Weight: 280g ±5%
- Dimensions: 52mm(L) × 38mm(W) × 64mm(H)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (with intermittent operation up to 100℃)
- Power consumption: 1.6W (DC), 3.5VA (AC)
- Port thread depth: 10mm (minimum engagement)
- Protection rating: IP67 (dustproof & temporary immersion)
- Cycle life: ≥10 million operations
High-flow proportional control valve with metal piston design, featuring anti-vibration terminals and surge protection circuitry. The optimized flow path geometry reduces pressure drop by 18% compared to previous generations. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.2.2 quality.
- Pneumatic cylinder sequencing in assembly lines
- Vacuum generator control in pick-and-place systems
- Dual-pressure regulation for injection molding machines
- Automated valve clusters in food packaging systems
- Process control in semiconductor handling equipment
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Maintain minimum 15mm clearance from adjacent components for heat dissipation.
Lubricate pivot points every 2,000 operating hours using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | 2KSH05010B |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC24V |
