Airtac 2KSH Fluid Control Valve 2KSH05010C
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH05010C Fluid Control Valve Technical Details
- Model: 2KSH05010C
- Type: 3-position, 5-way closed center (double solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10%)
- Flow capacity: 850 L/min (ANR) at 0.5 MPa
- Weight: 350g ±5% (including coil)
- Dimensions: 80mm(L) × 40mm(W) × 60mm(H)
- Valve body material: Reinforced PBT resin
- Seal material: HNBR rubber (high-temperature nitrile)
- Temperature range: -10℃ to 90℃ (non-freezing)
- Response time: ≤20ms (at rated voltage)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with dual solenoid activation, featuring anti-vibration terminals and surge protection circuitry. The encapsulated coil design prevents moisture ingress in humid environments. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3.2.4 purity standards.
- Semiconductor wafer handling robotics
- Bottle molding machine clamp control
- Automated paint mixing systems
- Pharmaceutical blister packaging lines
- Food-grade gas control (FDA-compliant variants)
Installation protocol:
Mount on ISO 5599/1 standard subplate (port SA). Maintain 20mm
clearance below valve for heat dissipation. Lubricate seals with
ISO VG32 turbine oil during maintenance.
Critical note:
Do NOT use silicone-based lubricants. Cycle rate must not exceed
5Hz continuous operation. Always install downstream pressure
regulator with 0.03MPa buffer margin.
| Property | Property Value |
|---|---|
| sku | 2KSH05010C |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC 110V |
