Airtac 2KSH Fluid Control Valve 2KSH05010F
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH Fluid Control Valve 2KSH05010F Technical Details
- Model: 2KSH05010F
- Type: 5-port 2-position directional control valve (pneumatic)
- Port size: 1/4" BSPP (G1/4)
- Operating pressure: 0.2–1.0 MPa
- Max flow rate: 850 L/min (ANR)
- Actuation type: Double solenoid (24VDC/AC110V/AC220V optional)
- Response time: ≤50 ms
- Seal material: Heat-resistant FKM (Fluorocarbon Rubber)
- Temperature range: -10℃ to 120℃
- Weight: 320g ±5%
- Dimensions: 65mm(L) × 45mm(W) × 85mm(H)
- Port thread depth: 12mm
- Protection rating: IP67 (dust/water resistant)
- Service life: ≥10 million cycles
High-flow proportional control valve with dual-coil electromagnetic actuation, featuring precision-machined stainless steel spool and industrial-grade corrosion resistance. The optimized flow path design reduces pressure drop by 18% compared to previous generations. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3 air quality.
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- Beverage filling station pneumatic circuits
- Automotive paint shop automation
- Semiconductor wafer handling equipment
Installation guidelines:
Mount horizontally with actuator facing downward for optimal drainage.
Use copper-based anti-seize compound on threaded ports.
Minimum 30mm clearance required below valve for maintenance access.
| Property | Property Value |
|---|---|
| sku | 2KSH05010F |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
