Airtac 2KSH Fluid Control Valve 2KSH05015AI
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH05015AI Fluid Control Valve Technical Details
- Full model designation: 2KSH05015AI (with manual override option)
- Valve type: 5-port 3-position closed center (closed transition)
- Port configuration: G1/4 (BSPP thread standard)
- Operating pressure range: 0.05–1.0 MPa (7-145 PSI)
- Maximum flow capacity: 1,200 NL/min (ANR)
- Actuation type: Double solenoid (24V DC ±10%)
- Coil insulation class: Class F (155℃)
- Seal material: HNBR (Hydrogenated Nitrile) for oil/fuel resistance
- Ambient temperature range: -10℃ to 60℃ (non-freezing)
- Weight: 850g ±3% (including coil assemblies)
- Body dimensions: 120mm(L) × 54mm(W) × 85mm(H)
- Port spacing: 25mm center-to-center vertical ports
- Response time: ≤35ms (both energize/de-energize)
- Protection rating: IP67 (dustproof/immersion protected)
- Mounting style: ISO 5599/1 subplate compatible
High-flow directional control valve with center-block function, featuring aluminum alloy body with hard anodized surface treatment. Designed for bi-directional fluid control in hydraulic/pneumatic hybrid systems. Integrated surge suppression prevents water hammer effects. Requires 10μm filtration (β10≥75) for optimal performance.
- Automated bottling line diverter valves
- CNC machine tool coolant control systems
- Food processing pneumatic actuators
- Wastewater treatment plant pump controls
- Mobile hydraulic equipment (agricultural machinery)
Installation guidelines:
Mount on vibration-damped surfaces using M5 mounting screws (torque 3.5Nm max).
Maintain 20mm clearance below valve for manifold access. Lubricate seals with
ISO VG32-grade oil if operating below -5℃. Perform monthly manual cycling
during standby periods.
| Property | Property Value |
|---|---|
| sku | 2KSH05015AI |
| Port Size | PT 1/2 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC220V |
