Airtac 2KSL Fluid Control Valve 2KSL03006A
2、Wide pressure range compatibility, available in ultra-high pressure (X), high pressure (H), standard, and large-flow (L) configurations;
3、Compact design with small footprint, lightweight construction, and tool-free assembly/disassembly;
4、SUS304 stainless steel valve body, Class B thermal-rated coil, and standard FPMF (fluororubber) seals compatible with various working media. Custom seal materials available upon consultation with our technical department;
5、IP65-rated coil protection, offering direct lead wire or DIN connector wiring options.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSL
AirTAC 2KSL03006A Fluid Control Valve Specifications
- Model: 2KSL03006A
- Type: 2-position 5-way solenoid valve (double solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 750 L/min (ANR)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Weight: 320g ±5% (including coil)
- Dimensions: 60mm(L) × 32mm(W) × 42mm(H)
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Power consumption: DC: 3.5W, AC: 4.2VA
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 10mm (minimum engagement)
- Cycle rate: ≥5 million operations (at rated conditions)
High-speed 5/2-way pneumatic valve with dual solenoid operation, featuring gold-plated pins for corrosion resistance and manual override capability. The aluminum alloy body with hard anodizing ensures durability in humid environments. Designed for applications requiring rapid cycling and precise directional control.
- Industrial automation sequencing systems
- Textile machinery cylinder control
- Bottle cap sorting mechanisms
- Automated assembly line actuators
- Semiconductor handling equipment
Installation note:
Use M5 mounting screws with 0.49–0.69N·m torque. Maintain minimum 15mm clearance below valve for tubing connections. For horizontal mounting, install coil connectors facing downward to prevent debris accumulation.
| Property | Property Value |
|---|---|
| sku | 2KSL03006A |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
