Airtac 2KSL Fluid Control Valve 2KSL03006B
2、Wide pressure range compatibility, available in ultra-high pressure (X), high pressure (H), standard, and large-flow (L) configurations;
3、Compact design with small footprint, lightweight construction, and tool-free assembly/disassembly;
4、SUS304 stainless steel valve body, Class B thermal-rated coil, and standard FPMF (fluororubber) seals compatible with various working media. Custom seal materials available upon consultation with our technical department;
5、IP65-rated coil protection, offering direct lead wire or DIN connector wiring options.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSL
AirTAC 2KSL Fluid Control Valve 2KSL03006B Technical Specifications
- Model: 2KSL03006B
- Type: 5/2-way single solenoid operated (monostable)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.15–1.0 MPa
- Proof pressure: 1.5 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Flow capacity: 850 l/min (ANR)
- Response time: ≤15ms (excitation), ≤20ms (reset)
- Seal material: Heat-resistant NBR (Nitrile)
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Port thread depth: 12mm
- Weight: 320g ±5%
- Dimensions: 58mm(L) × 42mm(W) × 87mm(H)
- Protection standard: IP67 (coil), IP40 (valve body)
- Electrical connection: DIN43650 Form A
High-flow proportional control valve with aluminum alloy body and brass internals, featuring zero-pressure differential start capability. The low-hysteresis design ensures precise flow regulation across 0.3-0.8 MPa working ranges. Includes manual override and LED status indicator. Requires 5μm filtered compressed air with oil mist lubrication (ISO VG32 recommended).
- Pneumatic cylinder sequencing in assembly lines
- Vacuum generator control in packaging systems
- Air pressure regulation for CNC machine tools
- Process control in semiconductor manufacturing
- Automated material handling systems
Installation guidelines:
Mount with vibration-damping brackets in environments exceeding 0.5G vibration.
Maintain 20mm clearance below valve for condensate drainage. Lubricate pilot valve
quarterly with ISO VG32 oil when used in dry air systems.
| Property | Property Value |
|---|---|
| sku | 2KSL03006B |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
