Airtac 2KSL Fluid Control Valve 2KSL03006BI
2、Wide pressure range compatibility, available in ultra-high pressure (X), high pressure (H), standard, and large-flow (L) configurations;
3、Compact design with small footprint, lightweight construction, and tool-free assembly/disassembly;
4、SUS304 stainless steel valve body, Class B thermal-rated coil, and standard FPMF (fluororubber) seals compatible with various working media. Custom seal materials available upon consultation with our technical department;
5、IP65-rated coil protection, offering direct lead wire or DIN connector wiring options.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSL
AirTAC 2KSL Fluid Control Valve 2KSL03006BI Technical Details
- Model: 2KSL03006BI
- Type: 3-position 5-way closed center (pneumatic pilot operation)
- Port configuration: 5 ports (P, A, B, EA, EB)
- Port thread size: G1/8 (ISO228 standard)
- Operating pressure range: 0.15–1.0 MPa
- Max flow capacity: 750 L/min (ANR)
- Actuation type: Double solenoid (24VDC ±10%)
- Coil power: 1.2W (Class F insulation)
- Response time: ≤50ms (both ON/OFF)
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Temperature range: -10℃ to 80℃ (no freezing)
- Body material: Anodized aluminum alloy (ADC12)
- Weight: 680g ±2%
- Dimensions: 108mm(L) × 54mm(W) × 80mm(H)
- Protection rating: IP67 (dust/water resistant)
- Service life: ≥10 million cycles (under rated conditions)
High-flow directional control valve with precision pilot mechanism, featuring dual manual override buttons for emergency operation. The dual-chamber design minimizes internal leakage (<0.1L/min) while maintaining rapid switching performance. Compatible with ISO 1 (VDMA) mounting systems.
- Plastic injection molding machine clamp control
- Automated assembly line cylinder sequencing
- Textile machinery pneumatic circuit switching
- Beverage filling system actuator control
- Semiconductor handling equipment vacuum/pressure switching
Installation guidelines:
Mount horizontally with pilot valves facing upward. Use 0.3-0.5Nm torque for port connections.
Lubricate with ISO VG32 turbine oil if operated below -5℃. Replace seals every 2 years under
continuous operation (8hrs/day).
Critical note:
Requires 5μm filtration (40μm for exhaust ports). Never apply silicone-based lubricants -
use phosphate ester-compatible grease only. Maintain 20mm clearance below valve for condensate drainage.
| Property | Property Value |
|---|---|
| sku | 2KSL03006BI |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
