Airtac 2KSL Fluid Control Valve 2KSL03006C
2、Wide pressure range compatibility, available in ultra-high pressure (X), high pressure (H), standard, and large-flow (L) configurations;
3、Compact design with small footprint, lightweight construction, and tool-free assembly/disassembly;
4、SUS304 stainless steel valve body, Class B thermal-rated coil, and standard FPMF (fluororubber) seals compatible with various working media. Custom seal materials available upon consultation with our technical department;
5、IP65-rated coil protection, offering direct lead wire or DIN connector wiring options.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSL
AirTAC 2KSL Fluid Control Valve 2KSL03006C Technical Specifications
- Model: 2KSL03006C
- Type: 3-position, 5-way closed center (double solenoid)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure range: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 350g ±5% (without connectors)
- Dimensions: 60mm(L) × 35mm(W) × 80mm(H) (excluding mounting brackets)
- Seal material: Heat-resistant NBR (Nitrile) compound
- Temperature tolerance: -20℃ to 80℃ (non-freezing environment)
- Flow capacity: 0.45 CV (at 0.5 MPa)
- Response time: ≤15ms (open), ≤20ms (close)
- Port thread depth: 12mm (minimum engagement)
- Protection class: IP67 (dust/water resistant)
High-performance directional control valve featuring dual-coil operation with manual override capability. The hardened aluminum body with anti-corrosion treatment ensures durability in humid environments. Designed for precise bi-directional flow control in medium-pressure pneumatic systems. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.2.3 air quality.
- Automated production line cylinder sequencing
- Packaging machinery clamp positioning systems
- Automotive assembly jig controls
- Food processing pneumatic actuators
- Semiconductor wafer handling robots
Installation guidelines:
Mount horizontally with arrow direction matching airflow. Maintain minimum 15mm
clearance around solenoid coils for heat dissipation. Use copper-free anti-seize
compound on threads. Cycle valve 3-5 times before initial operation.
| Property | Property Value |
|---|---|
| sku | 2KSL03006C |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
