Airtac 2KSL Fluid Control Valve 2KSL03006CI
2、Wide pressure range compatibility, available in ultra-high pressure (X), high pressure (H), standard, and large-flow (L) configurations;
3、Compact design with small footprint, lightweight construction, and tool-free assembly/disassembly;
4、SUS304 stainless steel valve body, Class B thermal-rated coil, and standard FPMF (fluororubber) seals compatible with various working media. Custom seal materials available upon consultation with our technical department;
5、IP65-rated coil protection, offering direct lead wire or DIN connector wiring options.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSL
AirTAC 2KSL Fluid Control Valve 2KSL03006CI Technical Details
- Model: 2KSL03006CI
- Type: 3-position closed center, 5-way pilot operated
- Port size: 1/4" NPT (G1/8 optional)
- Operating pressure: 0.05–0.8 MPa (7-116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 480g ±5% (with accessories)
- Dimensions: 60mm(L) × 42mm(W) × 78mm(H) (excluding fittings)
- Seal material: FKM fluorocarbon rubber (standard), EPDM optional
- Temperature range: -10℃ to 80℃ (with FKM seals)
- Flow capacity: 850 L/min (ANR) at 0.5 MPa
- Response time: ≤50ms (exhaust to actuation)
- Protection rating: IP67 (dustproof and temporary immersion)
- Manual override: Built-in emergency switch
High-flow proportional control valve with center-block function, featuring brass body construction with chrome-plated spool for reduced friction. Optimized for precision flow modulation in closed-loop systems. Requires 5μm filtered compressed air with oil mist (ISO 8573-1 Class 3.4.2). Includes surge suppression circuit for coil protection.
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changer positioning mechanisms
- Food processing pneumatic circuits (EPDM seal version)
- Semiconductor wafer handling robotics
Installation guidelines:
Mount horizontally with arrow aligned to airflow direction.
Use vibration-damping brackets in high-shock environments.
Allow 15mm clearance below valve for condensate drainage.
Critical note:
Do not use with phosphate ester-based lubricants.
Cycle rate limited to ≤5Hz continuous operation.
Requires 2-second minimum power-off period between actuations.
| Property | Property Value |
|---|---|
| sku | 2KSL03006CI |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
