Airtac 2KSL Fluid Control Valve 2KSL03006F
2、Wide pressure range compatibility, available in ultra-high pressure (X), high pressure (H), standard, and large-flow (L) configurations;
3、Compact design with small footprint, lightweight construction, and tool-free assembly/disassembly;
4、SUS304 stainless steel valve body, Class B thermal-rated coil, and standard FPMF (fluororubber) seals compatible with various working media. Custom seal materials available upon consultation with our technical department;
5、IP65-rated coil protection, offering direct lead wire or DIN connector wiring options.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSL
AirTAC 2KSL Fluid Control Valve 2KSL03006F Technical Details
- Model: 2KSL03006F
- Type: 5/2-way pilot-operated solenoid valve (double coil)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V, DC24V, AC110V(50/60Hz), AC220V(50/60Hz)
- Flow coefficient (Cv): 1.8
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Ambient temperature: -20℃ to 80℃ (-4°F to 176°F)
- Power consumption: 2.5W (AC), 2.8W (DC)
- Protection class: IP67 (dustproof & temporary immersion resistant)
- Weight: 480g (1.06 lbs) ±3%
- Dimensions: 60mm(L) × 45mm(W) × 78mm(H) (2.36" × 1.77" × 3.07")
- Port thread depth: 12mm (male thread)
- Max operating frequency: 5Hz (300 cycles/minute)
High-flow directional control valve with dual coil configuration for precise pneumatic circuit switching. Features anti-vibration design with copper alloy solenoid components and hardened stainless steel spool. The optimized pilot chamber structure ensures stable operation under pressure fluctuations. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3 air quality.
- Automated assembly line clamping systems
- Plastic injection molding machine ejectors
- CNC tool changers with rapid cylinder cycling
- Textile machinery air-jet looms
- Bottle capping/palletizing systems
- Semiconductor wafer handling robots
Installation protocol:
Mount in vibration-free area using M5 mounting screws (torque ≤0.8N·m).
Maintain ≥15mm clearance around valve body for heat dissipation.
Lubricate spool monthly with ISO VG32 turbine oil in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | 2KSL03006F |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
