Airtac 2KSL Fluid Control Valve 2KSL03008AI
2、Wide pressure range compatibility, available in ultra-high pressure (X), high pressure (H), standard, and large-flow (L) configurations;
3、Compact design with small footprint, lightweight construction, and tool-free assembly/disassembly;
4、SUS304 stainless steel valve body, Class B thermal-rated coil, and standard FPMF (fluororubber) seals compatible with various working media. Custom seal materials available upon consultation with our technical department;
5、IP65-rated coil protection, offering direct lead wire or DIN connector wiring options.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSL
AirTAC 2KSL Fluid Control Valve 2KSL03008AI Technical Details
- Model: 2KSL03008AI
- Type: 3-position, 5-way closed center (Pilot-operated)
- Port configuration: 5 ports (P, A, B, EA, EB)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.1–0.8 MPa
- Max flow rate: 750 L/min (ANR)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Weight: 350g ±5% (including coil)
- Dimensions: 80mm(L) × 40mm(W) × 60mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) for improved chemical resistance
- Temperature range: -10℃ to 70℃ (non-freezing)
- Power consumption: 2.8W (DC), 3.5VA (AC)
- Response time: ≤30ms (at 0.5MPa)
- Protection rating: IP67 (coil), IP40 (valve body)
- Cycle life: ≥10 million operations
High-flow proportional control valve with closed-center configuration, featuring precision-machined spool and dual pressure balancing chambers. The aluminum alloy body with hard anodized treatment ensures corrosion resistance in humid environments. Includes manual override and position indicator for maintenance operations. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.3 air quality standard.
- Automated assembly line clamping systems
- Plastic injection molding machine sequence control
- Semiconductor wafer handling robotics
- Beverage filling station pneumatic circuits
- Solar panel cleaning system actuators
Installation guidelines:
Mount horizontally with arrow direction matching airflow. Maintain minimum
20mm clearance below valve for exhaust ports. Use copper-free grease on
thread connections. Perform weekly manual cycling during standby periods.
Critical note:
Do not apply silicone-based lubricants. Requires surge protection
circuit for AC coils. Maximum allowable momentary pressure spike: 1.2MPa.
| Property | Property Value |
|---|---|
| sku | 2KSL03008AI |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
