Airtac 2KSL Fluid Control Valve 2KSL05010B
2、Wide pressure range compatibility, available in ultra-high pressure (X), high pressure (H), standard, and large-flow (L) configurations;
3、Compact design with small footprint, lightweight construction, and tool-free assembly/disassembly;
4、SUS304 stainless steel valve body, Class B thermal-rated coil, and standard FPMF (fluororubber) seals compatible with various working media. Custom seal materials available upon consultation with our technical department;
5、IP65-rated coil protection, offering direct lead wire or DIN connector wiring options.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSL
AirTAC 2KSL05010B Fluid Control Valve Specifications
- Model: 2KSL05010B
- Type: 5-port 2-position directional control valve (monostable)
- Port size: G1/8 (ISO228/1 standard)
- Thread type: Parallel (BSPP)
- Operating pressure: 0.2–1.0 MPa (29–145 psi)
- Max flow rate: 850 L/min (Cv=1.2 at 0.5 MPa)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Weight: 0.68 kg (1.5 lbs) ±5%
- Dimensions: 56mm(L) × 46mm(W) × 95mm(H) (2.2"×1.8"×3.7")
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Temperature range: -10℃ to 80℃ (14℉ to 176℉)
- Response time: ≤30ms (at rated voltage)
- Power consumption: 3.5W (DC), 5VA (AC)
- Protection rating: IP67 (dustproof and waterproof)
- Manual override: Built-in emergency switch
- Mounting: ISO 5599-1 compliant sub-base
High-flow compact directional valve with low power consumption design, featuring corrosion-resistant aluminum alloy body and gold-plated pins for reliable electrical connection. The optimized spool structure ensures ≤0.1 MPa minimum operating pressure difference. Compatible with ISO VG32 hydraulic oil and most industrial compressed air systems (requires 5μm filtration).
- Pneumatic cylinder control in assembly lines
- Material handling equipment sequencing
- Textile machinery air circuit switching
- Automated test bench fluid control
- Semiconductor manufacturing actuators
Installation note:
For optimal performance, maintain ambient temperature below 60℃ and install with
vibration-damping mounts in high-shock environments. Lubricate seals with ISO VG32
oil if operating in dry air conditions. Allow ≥20mm clearance below valve for
maintenance access.
| Property | Property Value |
|---|---|
| sku | 2KSL05010B |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
