Airtac 2KSL Fluid Control Valve 2KSL05010CI
2、Wide pressure range compatibility, available in ultra-high pressure (X), high pressure (H), standard, and large-flow (L) configurations;
3、Compact design with small footprint, lightweight construction, and tool-free assembly/disassembly;
4、SUS304 stainless steel valve body, Class B thermal-rated coil, and standard FPMF (fluororubber) seals compatible with various working media. Custom seal materials available upon consultation with our technical department;
5、IP65-rated coil protection, offering direct lead wire or DIN connector wiring options.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSL
AirTAC 2KSL05010CI Fluid Control Valve Specifications
- Model: 2KSL05010CI
- Type: 2-position, 5-port closed center (Pilot-operated)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.2–1.0 MPa (29–145 psi)
- Maximum flow rate: 750 L/min (Cv=1.3 at 0.5 MPa)
- Voltage options: DC12V (±10%), DC24V (±10%)
- Coil power: 1.6W (DC24V), 2.2W (DC12V)
- Weight: 320g ±5% (including coil)
- Dimensions: 58mm(L) × 45mm(W) × 76mm(H)
- Seal material: HNBR rubber (Hydrogenated Nitrile)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Response time: ≤30ms (at rated voltage)
- Port thread depth: 12mm (minimum engagement)
- Protection rating: IP67 (coil), IP40 (valve body)
- Compatible fluids: Air (ISO8573-1:2010 Class 3.4.3)
High-flow proportional control valve with closed-center spool design, featuring precision-machined aluminum alloy body and corrosion-resistant plating. The dual-coil configuration enables momentary operation with pulse-width modulation (PWM) compatibility. Includes manual override and position detection switch compatibility via M5 connector.
- Industrial automation sequencing systems
- Plastic injection molding machine clamp control
- Textile machinery tension regulation
- Beverage filling line pressure modulation
- Semiconductor wafer handling robotics
Installation note:
Mount horizontally with arrow aligned to flow direction. Use 5Nm torque for port fittings.
Install downstream filter (5μm) and lubricator if pneumatic system lacks central conditioning.
| Property | Property Value |
|---|---|
| sku | 2KSL05010CI |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
