Airtac 2KSL Fluid Control Valve 2KSL05010F
2、Wide pressure range compatibility, available in ultra-high pressure (X), high pressure (H), standard, and large-flow (L) configurations;
3、Compact design with small footprint, lightweight construction, and tool-free assembly/disassembly;
4、SUS304 stainless steel valve body, Class B thermal-rated coil, and standard FPMF (fluororubber) seals compatible with various working media. Custom seal materials available upon consultation with our technical department;
5、IP65-rated coil protection, offering direct lead wire or DIN connector wiring options.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSL
AirTAC 2KSL05010F Fluid Control Valve Specifications
- Model: 2KSL05010F
- Type: 5/2-way single solenoid control (spring return)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 1.2
- Max flow rate: 650 NL/min
- Response time: ≤15ms (actuation), ≤20ms (reset)
- Weight: 420g ±5% (excluding connectors)
- Dimensions: 56mm(W) × 56mm(H) × 128mm(L)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 60℃ (operating fluid), -20℃ to 80℃ (ambient)
- Power consumption: 1.6W (DC), 2.3VA (AC)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with precision-machined aluminum body and hardened stainless steel spool. Features dual-color LED status indicator (red/green) and manual override button. Designed for rapid cycling applications with 100% ED (continuous duty) rating. Requires ISO 8573-1:2010 Class 3.4.2 compressed air (max 50μm particle size, -20℃ dew point).
- Automated assembly line actuators
- Plastic injection molding machine clamp control
- CNC tool changers and spindle brakes
- Textile machinery tensioning systems
- Food processing pneumatic circuits (oil-free version available)
Installation guidelines:
Mount in vibration-free environment using M5 mounting screws (torque ≤0.8N·m).
Maintain 20mm clearance below valve for solenoid heat dissipation.
Use locknuts with PTFE sealant on ports. Lubricate with ISO VG32 turbine oil if
operating below -5℃.
| Property | Property Value |
|---|---|
| sku | 2KSL05010F |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
