Airtac 2KSL Fluid Control Valve 2KSL05010FI
2、Wide pressure range compatibility, available in ultra-high pressure (X), high pressure (H), standard, and large-flow (L) configurations;
3、Compact design with small footprint, lightweight construction, and tool-free assembly/disassembly;
4、SUS304 stainless steel valve body, Class B thermal-rated coil, and standard FPMF (fluororubber) seals compatible with various working media. Custom seal materials available upon consultation with our technical department;
5、IP65-rated coil protection, offering direct lead wire or DIN connector wiring options.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSL
AirTAC 2KSL05010FI Fluid Control Valve Specifications
- Model: 2KSL05010FI
- Type: 5-port 3-position closed center (pneumatic pilot operated)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%)
- Weight: 480g ±5%
- Dimensions: 78mm(L) × 50mm(W) × 105mm(H)
- Seal material: Fluororubber (FKM) standard (NBR optional)
- Temperature range: -10℃ to 80℃ (with FKM seals)
- Flow capacity: 1,200 NL/min (at 0.5 MPa)
- Response time: ≤80ms (at rated voltage)
- Protection rating: IP67 (dust/water resistant)
- Manual override: Built-in emergency operation button
High-flow proportional control valve with closed-center configuration, featuring aluminum alloy body with hard anodized finish for corrosion resistance. The dual solenoid design enables precise mid-position shutoff control. Requires 5μm filtered compressed air (ISO 8573-1 class 3.4.2) and 20-50 cSt viscosity lubricant if used.
- Industrial automation clamping systems
- Plastic injection molding machines
- Food processing pneumatic circuits
- Water treatment plant valve clusters
- Medical device actuation systems
- Automated assembly line tooling
Installation note:
Mount with vibration-damping brackets in horizontal orientation.
Maintain minimum 15mm clearance around valve body for heat dissipation.
Use copper-free anti-seize compound on threaded ports.
Critical:
Do NOT use with oxygen or combustible gases.
Cycle frequency must not exceed 5Hz continuously.
Install downstream pressure gauge for closed-loop systems.
| Property | Property Value |
|---|---|
| sku | 2KSL05010FI |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
