Airtac 2KWH Fluid Solenoid Valve 2KWH03006AI
2. Extensive pressure range adaptability with model options: Ultra-high pressure (X), High pressure (H), Standard, and Large flow capacity (L);
3. Compact design with minimized footprint, lightweight construction, and tool-free installation for enhanced maintenance efficiency;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer) seals ensure compatibility across diverse media. Customizable seal materials available upon technical consultation;
5. IP65-rated coil protection and multiple wiring configurations: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWH
AirTAC 2KWH Fluid Solenoid Valve 2KWH03006AI Technical Details
- Model: 2KWH03006AI
- Type: 2-position, 3-way direct-acting solenoid valve
- Port size: 1/8" NPT (G1/8 optional)
- Flow capacity: 0.8 Cv (Kv=0.7)
- Operating pressure: 0.02–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%)
- Power consumption: 2.5W (DC24V)
- Response time: ≤15ms (open/close)
- Seal material: FKM (Viton®) fluorocarbon rubber
- Temperature range: -10℃ to 150℃ (fluid), -5℃ to 80℃ (ambient)
- Protection rating: IP67 (dust/water resistant)
- Weight: 280g ±5g
- Dimensions: 58mm(L) × 35mm(W) × 45mm(H)
- Port thread depth: 10mm (minimum engagement)
- Max viscosity: 50 cSt (fluid requirement)
High-precision fluid control valve with triple-seal structure for aggressive media handling. Features military-grade epoxy coating and gold-plated terminals for corrosion resistance. The zero-pressure differential start capability enables reliable operation in low-pressure systems (≥0.02MPa). Designed for 1 million+ cycle durability with ≤0.1% leakage rate.
- Chemical dosing systems (acid/alkali solutions)
- Medical device fluid circuits (sterile liquid control)
- Semiconductor wafer cleaning equipment
- Food-grade lubricant dispensing machines
- Hydraulic pilot stage control
- Automotive test bench cooling circuits
Installation protocol:
Requires 10μm filtration upstream. Must be mounted with ±5° tolerance from vertical position.
Perform 10-cycle manual actuation before initial use. Maintenance interval: 5,000 operating hours
or 6 months (whichever comes first) for seal inspection.
| Property | Property Value |
|---|---|
| sku | 2KWH03006AI |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC220V |
