Airtac 2KWH Fluid Solenoid Valve 2KWH03006C
2. Extensive pressure range adaptability with model options: Ultra-high pressure (X), High pressure (H), Standard, and Large flow capacity (L);
3. Compact design with minimized footprint, lightweight construction, and tool-free installation for enhanced maintenance efficiency;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer) seals ensure compatibility across diverse media. Customizable seal materials available upon technical consultation;
5. IP65-rated coil protection and multiple wiring configurations: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWH
AirTAC 2KWH03006C Fluid Solenoid Valve Technical Details
- Model: 2KWH03006C
- Valve type: 2-position 5-way direct acting (double solenoid)
- Port configuration: PT1/4 (G1/4 optional)
- Operating pressure range: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Maximum flow rate: 1,000 NL/min (ANR at 0.5 MPa)
- Seal material: HNBR rubber (high nitrile for chemical resistance)
- Valve body material: Die-cast aluminum with hard anodized finish
- Ambient temperature range: -5℃ to 80℃ (operating fluid temp: 0-60℃)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Response time: ≤15ms (at rated voltage)
- Protection class: IP67 (dustproof and waterproof)
- Weight: 650g ±5% (without connectors)
- Dimensions: 100mm(L) × 50mm(W) × 50mm(H) (excluding mounting brackets)
- Port thread depth: 12mm (full thread engagement required)
High-flow proportional control valve with dual solenoid configuration, engineered for precise directional control in hydraulic/pneumatic hybrid systems. Features multi-stage sealing with wear compensation and surge protection circuitry. Requires 10μm filtration (25μm max) and automatic drain installation in high-humidity environments.
- Automated liquid dispensing systems (adhesives, lubricants)
- Hydraulic press sequencing controls
- Semiconductor wafer cleaning equipment
- Beverage filling line pressure regulation
- Electric vehicle battery cooling circuits
Operational guidelines:
Maintain fluid viscosity between 10-150 cSt. Install vibration dampeners when
mounted on reciprocating machinery. Perform manual cycling weekly during standby
periods to prevent seal hardening. Coil replacement requires torque-limited
fastening (0.8-1.2 N·m).
| Property | Property Value |
|---|---|
| sku | 2KWH03006C |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC 110V |
