Airtac 2KWH Fluid Solenoid Valve 2KWH03006F
2. Extensive pressure range adaptability with model options: Ultra-high pressure (X), High pressure (H), Standard, and Large flow capacity (L);
3. Compact design with minimized footprint, lightweight construction, and tool-free installation for enhanced maintenance efficiency;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer) seals ensure compatibility across diverse media. Customizable seal materials available upon technical consultation;
5. IP65-rated coil protection and multiple wiring configurations: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWH
AirTAC 2KWH03006F Fluid Solenoid Valve Technical Details
- Model: 2KWH03006F (Full designation: 2KWH030-06F)
- Valve type: 2-position 3-way normally closed (pilot-operated)
- Port configuration: 3/2-way with ISO G1/8" (BSPP) threaded ports
- Effective section area: 7.5mm² for precise flow control
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Power consumption: 1.6W (DC) / 3.5VA (AC)
- Response time: ≤15ms (open), ≤20ms (close)
- Seal material: High-grade FKM (Viton®) fluorocarbon rubber
- Fluid compatibility: Air, inert gases, light hydraulic oils (ISO VG32 or thinner)
- Ambient temperature: -5℃ to 80℃ (with 0.5%RH–95%RH non-condensing)
- Protection rating: IP67 (dustproof & temporary immersion resistant)
- Weight: 270g ±5g (including coil)
- Dimensions: 54mm (L) × 38mm (W) × 72mm (H)
- Port alignment: 25mm center-to-center vertical spacing
High-flow compact solenoid valve with dynamic pressure compensation, featuring brass body with electroless nickel plating for corrosion resistance. The dual-coil heat dissipation design enables continuous duty cycle operation. Requires 5μm filtered fluid with lubricator (ISO 8573-1:2010 Class 4.4.3). Optional manual override version available (add "-M" suffix).
- Plastic injection molding machine clamp controls
- CNC tool changer pneumatic sequencing
- Beverage filling line actuator systems
- Semiconductor wafer handling robotics
- Mobile hydraulic quick-release circuits
Installation guidelines:
Mount horizontally with coil upright (max 15° deviation allowed).
Use copper-free anti-seize compound on threads.
For AC coils, install surge suppressor within 5m wiring distance.
| Property | Property Value |
|---|---|
| sku | 2KWH03006F |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC12V |
