Airtac 2KWH Fluid Solenoid Valve 2KWH03006FI
2. Extensive pressure range adaptability with model options: Ultra-high pressure (X), High pressure (H), Standard, and Large flow capacity (L);
3. Compact design with minimized footprint, lightweight construction, and tool-free installation for enhanced maintenance efficiency;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer) seals ensure compatibility across diverse media. Customizable seal materials available upon technical consultation;
5. IP65-rated coil protection and multiple wiring configurations: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWH
AirTAC 2KWH03006FI Fluid Solenoid Valve Technical Details
- Model: 2KWH03006FI
- Type: 2-position, 3-way direct-acting (Normally Closed)
- Port configuration: G1/8 (BSPP thread)
- Operating medium: Compressed air, inert gases (oil-free required)
- Pressure range: 0.05–1.0 MPa (72.5–145 psi)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 0.72
- Response time: ≤15ms (actuation), ≤20ms (release)
- Seal material: High-grade FKM (Viton® equivalent)
- Ambient temperature: -20℃ to +80℃ (non-freezing)
- Power consumption: 3.5W (AC), 4.2W (DC)
- Protection class: IP67 (dust/water resistant)
- Weight: 280g ±5g (with coil)
- Dimensions: 56mm(L) × 37mm(W) × 76mm(H) (body only)
- Port spacing: 18mm center-to-center (horizontal ports)
High-flow proportional solenoid valve featuring brass body with electroless nickel plating for superior corrosion resistance. The dual-coil heat dissipation design enables continuous duty cycle operation. Integrated LED status indicator and DIN43650 connector compatibility. Requires 5μm filtration upstream.
- Pneumatic actuator control in CNC machinery
- Vacuum pump systems switching
- Industrial cleaning equipment pressure regulation
- Beverage filling line manifold assemblies
- Semiconductor manufacturing gas control
Installation guidelines:
Mount in vibration-free environment using M4 mounting screws (not included).
Maintain minimum 15mm clearance below valve for connector access.
Pipe alignment must avoid mechanical stress on body ports.
Critical note:
Not compatible with steam or aggressive chemicals.
Always install downstream moisture separator.
Maximum 100,000 cycles between maintenance (lubrication required).
| Property | Property Value |
|---|---|
| sku | 2KWH03006FI |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC12V |
