Airtac 2KWH Fluid Solenoid Valve 2KWH03008BI
2. Extensive pressure range adaptability with model options: Ultra-high pressure (X), High pressure (H), Standard, and Large flow capacity (L);
3. Compact design with minimized footprint, lightweight construction, and tool-free installation for enhanced maintenance efficiency;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer) seals ensure compatibility across diverse media. Customizable seal materials available upon technical consultation;
5. IP65-rated coil protection and multiple wiring configurations: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWH
AirTAC 2KWH03008BI Fluid Solenoid Valve Specifications
- Model: 2KWH03008BI
- Type: 2-position 3-way normally closed (pilot-operated)
- Port size: PT3/8 (NPT1/2 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC220V (50/60Hz)
- Coil class: Class F (155℃) with thermal protection
- Flow capacity: CV 1.8 (Kv 1.56)
- Response time: ≤25ms (open/close cycle)
- Seal material: FKM (Fluorocarbon) standard (NBR optional)
- Temperature range: -5℃ to 80℃ (fluid temperature)
- Ambient temperature: -20℃ to 60℃
- Weight: 680g ±5% (excluding accessories)
- Dimensions: 73mm(L) × 48mm(W) × 105mm(H)
- Port thread depth: 12mm (full engagement required)
- Power consumption: 3.5W (DC24V), 5VA (AC220V)
- Protection rating: IP67 (coil), IP65 (valve body)
- Certification: CE, RoHS, REACH compliant
High-flow proportional control valve with brass main body and reinforced PPS coil housing. Features zero-pressure differential start capability and anti-water hammer design. Requires 10μm filtration (25μm max) with lubricated or non-lubricated air. Optional manual override available (horizontal slider type).
- Pneumatic conveyor systems in food processing
- Coolant flow control in CNC machining centers
- Vacuum pump switching in packaging lines
- Process gas regulation in pharmaceutical equipment
- Water treatment plant pneumatic actuators
- Chemical dosing systems with aggressive media
Installation guidelines:
Mount in vibration-free environment using M5 mounting brackets (included).
Maintain minimum 15mm clearance around coil for heat dissipation.
Pipe connections must be torque-limited to 18-20 N·m.
Perform monthly seal integrity checks in high-cycle applications (>500,000 cycles/year).
| Property | Property Value |
|---|---|
| sku | 2KWH03008BI |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC24V |
