Airtac 2KWH Fluid Solenoid Valve 2KWH03008C
2. Extensive pressure range adaptability with model options: Ultra-high pressure (X), High pressure (H), Standard, and Large flow capacity (L);
3. Compact design with minimized footprint, lightweight construction, and tool-free installation for enhanced maintenance efficiency;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer) seals ensure compatibility across diverse media. Customizable seal materials available upon technical consultation;
5. IP65-rated coil protection and multiple wiring configurations: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWH
AirTAC 2KWH03008C Fluid Solenoid Valve Technical Details
- Model: 2KWH03008C
- Type: 3-way (3/2) normally closed direct-acting solenoid valve
- Port size: G1/8 (ISO228 standard)
- Operating pressure range: 0.05–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Flow coefficient (Cv): 0.65
- Seal material: FKM (Fluorocarbon Rubber) standard (NBR optional)
- Temperature range: -10℃ to 80℃ (with FKM seals)
- Response time: ≤15ms (open), ≤20ms (close)
- Protection class: IP67 (dustproof & temporary immersion)
- Port thread depth: 12mm (male threads)
- Weight: 320g ±5%
- Dimensions: 53mm(L) × 38mm(W) × 68mm(H) (excluding connectors)
High-flow compact solenoid valve featuring brass body with electroless nickel plating for corrosion resistance. Designed for aggressive media control with 300,000+ cycle durability. Requires 25μm filtration (40μm max) and lubricant-free operation. Manual override version available (add "-M" suffix).
- Coolant control in CNC machining centers
- Chemical dosing systems (compatible with pH 4-10 fluids)
- Reverse osmosis water treatment plants
- Food-grade liquid dispensing (FDA-compliant seal options)
- Hydraulic pilot stage control
Installation guidelines:
Mount with flow arrow aligned to system direction. Allow 15mm clearance for coil heat dissipation.
Use thread sealant (PTFE tape prohibited). Maximum ambient vibration: 50m/s².
| Property | Property Value |
|---|---|
| sku | 2KWH03008C |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC 110V |
