Airtac 2KWH Fluid Solenoid Valve 2KWH03008F
2. Extensive pressure range adaptability with model options: Ultra-high pressure (X), High pressure (H), Standard, and Large flow capacity (L);
3. Compact design with minimized footprint, lightweight construction, and tool-free installation for enhanced maintenance efficiency;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer) seals ensure compatibility across diverse media. Customizable seal materials available upon technical consultation;
5. IP65-rated coil protection and multiple wiring configurations: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWH
AirTAC 2KWH03008F Fluid Solenoid Valve Technical Details
- Model: 2KWH03008F
- Type: 2-position, 3-way normally closed (direct-acting)
- Port size: G1/8 (ISO228 standard)
- Operating pressure: 0.02–0.8 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC24V (±10%), AC110V (±15%), AC220V (±15%)
- Flow coefficient (Cv): 0.25
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Weight: 285g ±5g
- Dimensions: 54mm(L) × 35mm(W) × 50mm(H) (excluding connectors)
- Seal material: FKM (Fluoroelastomer) standard, EPDM optional
- Fluid temperature range: -5℃ to 80℃ (with FKM seals)
- Ambient temperature range: -20℃ to 60℃
- Power consumption: 3.5W (DC), 4.2VA (AC)
- Protection rating: IP67 (dustproof and temporary immersion protected)
- Port thread depth: 12mm (minimum engagement)
- Max viscosity: 50mm²/s (cSt)
High-precision liquid control valve with stainless steel plunger system, featuring bubble-tight shutoff capability. The brass body with electroless nickel plating ensures corrosion resistance in aggressive media. Designed for continuous duty cycles with 100% ED rating. Requires 25μm filtration upstream.
- Industrial coolant circulation systems
- Chemical dosing pumps in water treatment plants
- Medical fluid handling equipment
- Beverage dispenser liquid control
- Hydraulic pilot stage control
- Semiconductor wet process tools
Installation guidelines:
Mount in any orientation except coil-down position.
Always install downstream strainer (mesh ≤25μm) and
maintain minimum 30cm straight pipe run before valve inlet.
For viscous fluids, preheat to ≤30cSt before operation.
| Property | Property Value |
|---|---|
| sku | 2KWH03008F |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC12V |
