Airtac 2KWH Fluid Solenoid Valve 2KWH05010AI
2. Extensive pressure range adaptability with model options: Ultra-high pressure (X), High pressure (H), Standard, and Large flow capacity (L);
3. Compact design with minimized footprint, lightweight construction, and tool-free installation for enhanced maintenance efficiency;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer) seals ensure compatibility across diverse media. Customizable seal materials available upon technical consultation;
5. IP65-rated coil protection and multiple wiring configurations: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWH
AirTAC 2KWH05010AI Fluid Solenoid Valve Specifications
- Model: 2KWH05010AI
- Type: 2-position 3-way normally closed (direct-acting)
- Port size: G1/8 (ISO228 standard)
- Fluid compatibility: Air, water, light oils (ISO VG32 or below)
- Operating pressure: 0.02–1.0 MPa (vacuum to 10 bar)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz)
- Max flow rate: 850 L/min (Cv=1.2 at 0.5MPa)
- Response time: ≤15ms (at 20℃ with 0.5MPa)
- Seal material: FKM (Fluorocarbon) standard, EPDM optional
- Body material: Brass with nickel plating
- Temperature range: -10℃ to 80℃ (extended to 120℃ with high-temp coil)
- Protection rating: IP67 (dustproof & temporary immersion)
- Electrical connection: DIN43650 Form A (standard flying lead optional)
- Weight: 420g ±5% (excluding fittings)
- Dimensions: 78mm(L) × 45mm(W) × 65mm(H) (port axis to coil face)
- Certification: CE, RoHS, REACH compliant
High-flow proportional control valve with bubble-tight shutoff capability, featuring a copper-free aluminum alloy coil housing for EMI resistance. The zero-pressure differential start design enables reliable operation in vacuum systems. Includes manual override and status indicator LED (red/green dual-color).
- Industrial coolant line control in CNC machines
- Reverse osmosis water treatment systems
- Medical gas distribution panels
- Beverage dispensing equipment
- Hydraulic pilot stage control
- Laboratory analytical instrument fluidics
Installation note:
Requires 10μm filtration upstream. For liquid applications, mount vertically with coil upward.
Allow 15-minute run-in period for new installations. Use thread sealant (PTFE tape prohibited).
Not compatible with glycol-based fluids or chlorinated solvents.
Minimum 1 sec ON/OFF cycle recommended to prevent coil overheating.
| Property | Property Value |
|---|---|
| sku | 2KWH05010AI |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC220V |
