Airtac 2KWH Fluid Solenoid Valve 2KWH05010BI
2. Extensive pressure range adaptability with model options: Ultra-high pressure (X), High pressure (H), Standard, and Large flow capacity (L);
3. Compact design with minimized footprint, lightweight construction, and tool-free installation for enhanced maintenance efficiency;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer) seals ensure compatibility across diverse media. Customizable seal materials available upon technical consultation;
5. IP65-rated coil protection and multiple wiring configurations: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWH
AirTAC 2KWH05010BI Fluid Solenoid Valve Technical Details
- Model: 2KWH05010BI
- Type: 2-position 3-way (2KWH series), normally closed
- Port size: G1/8 (ISO228 standard)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC24V (±10%) / AC24V (50/60Hz)
- Fluid temperature range: -5℃ to 80℃
- Body material: Stainless steel (SUS304)
- Seal material: FKM (Fluorocarbon Rubber)
- Protection rating: IP67 (dustproof & waterproof)
- Response time: ≤15ms (at 20℃ nominal pressure)
- Power consumption: 2.8W (DC) / 3.5VA (AC)
- Weight: 320g ±5% (excluding connector)
- Dimensions: 80mm(L) × 35mm(W) × 60mm(H)
- Port thread depth: 12mm (male thread)
- Max viscosity: 50 cSt (requires heated fluid option above)
High-flow proportional control valve with zero-pressure differential start capability, featuring brass-free construction for chemical resistance. The pilot-operated design enables stable operation under pulsating flows. Includes surge protection circuitry and manual override button for system debugging. Compatible with water, compressed air, and light oils (ISO VG32 or lower).
- Precision dosing systems in pharmaceutical production
- Coolant flow control for CNC machining centers
- Automated liquid filling/packaging lines
- Hydraulic pilot stage control
- Semiconductor wafer cleaning equipment
Installation requirements:
Maintain vertical installation (±15° tolerance). Install 10μm filter upstream.
For continuous duty cycles, maintain fluid velocity ≤3m/s. Allow 15mm clearance
around coil for heat dissipation. Pipe connections require 0.3-0.5Nm torque.
| Property | Property Value |
|---|---|
| sku | 2KWH05010BI |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC24V |
