Airtac 2KWH Fluid Solenoid Valve 2KWH05010C
2. Extensive pressure range adaptability with model options: Ultra-high pressure (X), High pressure (H), Standard, and Large flow capacity (L);
3. Compact design with minimized footprint, lightweight construction, and tool-free installation for enhanced maintenance efficiency;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer) seals ensure compatibility across diverse media. Customizable seal materials available upon technical consultation;
5. IP65-rated coil protection and multiple wiring configurations: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWH
AirTAC 2KWH05010C Fluid Solenoid Valve Specifications
- Model: 2KWH05010C
- Type: 2-position, 2-way normally closed (direct-acting)
- Port size: PT1/2 (G1/2 optional)
- Operating pressure: 0.02–1.0 MPa
- Max pressure: 1.5 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 4.8W (DC), 5.5VA (AC)
- Flow coefficient (Cv): 2.0
- Seal material: FKM (Viton) fluorocarbon rubber
- Body material: Brass with nickel plating
- Temperature range: -10℃ to 80℃ (fluid temperature)
- Ambient temperature: -5℃ to 50℃
- Protection rating: IP67 (with DIN connector)
- Response time: ≤15ms (open/close)
- Weight: 820g ±3%
- Dimensions: 100mm(L) × 55mm(W) × 62mm(H) (excluding connections)
High-flow solenoid valve designed for aggressive fluids and viscous media control. Features enhanced corrosion resistance through nickel-plated brass body and Viton seals. Direct-acting design ensures reliable operation even with low differential pressure. Includes surge protection circuit and manual override capability.
- Industrial coolant circulation systems
- Chemical dosing equipment
- High-pressure wash station controls
- Hydraulic oil management systems
- Food-grade liquid dispensing machines
- Wastewater treatment plant actuators
Installation requirements:
Requires 100μm filtration upstream. Maximum allowable viscosity: 22 cSt.
For vertical installation, ensure coil faces upward. Use thread sealant compatible with hydraulic fluids.
| Property | Property Value |
|---|---|
| sku | 2KWH05010C |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC 110V |
