Airtac 2KWL Fluid Solenoid Valve 2KWL03006BI
2. Wide pressure range adaptability, offering Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) models;
3. Compact design with minimized footprint, reduced weight, and tool-free modular assembly for easy maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (Fluorocarbon Rubber) seals compatible with diverse media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection, wiring options include Lead Wire or DIN Connector configurations.
**Category**: Fluid Solenoid Valve | **Brand**: AirTAC | **Series**: 2KWL
AirTAC 2KWL03006BI Fluid Solenoid Valve Technical Details
- Model: 2KWL03006BI
- Type: 2-position, 3-way direct-acting (bi-stable)
- Port configuration: G3/8 (ISO228-1) with optional NPT1/4 threads
- Operating pressure range: 0.05–1.0 MPa (vacuum to 10 bar)
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: F grade (155℃)
- Flow coefficient (Cv): 1.8 (at 7 bar)
- Response time: ≤15ms (actuation), ≤20ms (release)
- Weight: 0.68 kg (with connector)
- Dimensions: 78mm(L) × 45mm(W) × 54mm(H) (excluding fittings)
- Body material: Anodized aluminum alloy (AL6063-T5)
- Seal compounds: HNBR main seals, FKM o-rings
- Ambient temperature: -5℃ to 80℃ (non-freezing)
- Power consumption: 4.8W (DC24V), 5.5VA (AC)
- Protection standard: IP67 (coil), IP40 (valve body)
- Port orientation: Axial flow design (IN/OUT on same axis)
High-flow proportional solenoid valve optimized for liquid/gas dual-media applications. Features anti-water-hammer design with built-in surge suppression and gold-plated terminals for corrosion resistance. Requires 25μm filtration (ISO 4406 17/15/12 class) and manual override capability for emergency operation.
- Coolant control in CNC machining centers
- Hydraulic pilot stage for pressurization systems
- Vacuum generator switching in pick-and-place robots
- Bi-directional flow control in chemical dosing systems
- Compressed air management in semiconductor cleanrooms
Installation protocol:
Mount with vibration-damping brackets (torque ≤0.8N·m). Maintain 15° maximum
deviation from vertical axis. Use thread sealant compatible with HNBR materials.
| Property | Property Value |
|---|---|
| sku | 2KWL03006BI |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC24V |
