Airtac 2KWL Fluid Solenoid Valve 2KWL03008AI
2. Wide pressure range adaptability, offering Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) models;
3. Compact design with minimized footprint, reduced weight, and tool-free modular assembly for easy maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (Fluorocarbon Rubber) seals compatible with diverse media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection, wiring options include Lead Wire or DIN Connector configurations.
**Category**: Fluid Solenoid Valve | **Brand**: AirTAC | **Series**: 2KWL
AirTAC 2KWL03008AI Fluid Solenoid Valve Specifications
- Model: 2KWL03008AI
- Type: 2-position, 2-way normally closed (direct-acting)
- Port size: 1/4" BSPP (G1/4)
- Fluid compatibility: Water, air, light oils (viscosity ≤22cSt)
- Operating pressure: 0~0.8 MPa (116 psi)
- Max flow rate: 35 L/min (water at 0.5 MPa)
- Voltage options: DC12V/24V ±10%, AC24V/110V/220V ±10% (50/60Hz)
- Power consumption: 4.8W (DC), 5.5VA (AC)
- Seal material: EPDM rubber (standard), optional FKM/Viton
- Temperature range: -5℃ to 80℃ (fluid/media)
- Ambient temperature: -20℃ to 50℃
- Protection rating: IP67 (dust/water resistant)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Weight: 310g ±5% (without connector)
- Dimensions: 78mm(L) × 54mm(W) × 44mm(H)
- Port thread depth: 12mm (both inlet/outlet)
- Manual override: Built-in emergency switch
High-flow fluid control valve with corrosion-resistant brass body and multi-voltage compatibility. Features surge suppression circuit for extended coil life (≥30 million cycles) and bubble-tight shutoff. Requires 50μm filtration upstream. Compatible with pulse-width modulation (PWM) control at ≤5Hz frequency.
- Industrial water cooling systems (CNC machines, laser cutters)
- Automated irrigation/pesticide spraying systems
- Beverage dispensing equipment flow control
- Chemical dosing pumps in water treatment plants
- Mobile hydraulic oil circulation systems
Installation guidelines:
Mount horizontally with ports downward to prevent sediment accumulation.
Use thread sealant (not Teflon tape) for leak-free connections.
Include bypass circuit for critical systems. Maintenance interval:
5,000 operating hours or 6 months (whichever comes first).
| Property | Property Value |
|---|---|
| sku | 2KWL03008AI |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC220V |
