Airtac 2KWL Fluid Solenoid Valve 2KWL03008E
2. Wide pressure range adaptability, offering Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) models;
3. Compact design with minimized footprint, reduced weight, and tool-free modular assembly for easy maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (Fluorocarbon Rubber) seals compatible with diverse media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection, wiring options include Lead Wire or DIN Connector configurations.
**Category**: Fluid Solenoid Valve | **Brand**: AirTAC | **Series**: 2KWL
AirTAC 2KWL03008E Fluid Solenoid Valve Specifications
- Model: 2KWL03008E
- Type: 2-position, 3-way normally closed (direct-acting)
- Port size: G1/8 (ISO228 standard)
- Effective diameter: 2.5mm (Cv≈0.12)
- Operating pressure: 0~0.8 MPa (vacuum to 0.8MPa)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Response time: ≤15ms (at 20℃ with ISO VG32 oil)
- Weight: 310g ±5g (with connector)
- Dimensions: 74mm(L) × 50mm(W) × 62mm(H) (excluding fittings)
- Seal material: FKM (Fluorocarbon Rubber) standard, EPDM/NBR optional
- Temperature range: -5℃ to 80℃ (FKM seals), -10℃ to 60℃ (NBR seals)
- Power consumption: 4.5W (DC24V), 5.5VA (AC220V)
- Protection rating: IP67 (connector installed)
- Fluid viscosity: 1~200 cSt
- Port thread depth: 12mm (internal threads)
High-flow fluid control valve with chemical-resistant construction, featuring brass body with electroless nickel plating. Designed for aggressive media including compressed air, water, light oils, and non-corrosive gases. Includes manual override and LED operation indicator. Requires 25μm filtration for optimal performance.
- Industrial coolant circulation systems
- Chemical dosing equipment
- Water treatment plant valve clusters
- Food-grade liquid dispensing machines
- Semiconductor wet process tools
- Hydraulic pilot stage control
Installation note:
Mount in any orientation except coil-down position. Use thread sealant on male ports only.
For pulsating flows, install 10cm downstream damping section. Maximum ambient vibration: 50m/s².
| Property | Property Value |
|---|---|
| sku | 2KWL03008E |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC24V |
