Airtac 2KWL Fluid Solenoid Valve 2KWL03008EI
2. Wide pressure range adaptability, offering Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) models;
3. Compact design with minimized footprint, reduced weight, and tool-free modular assembly for easy maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (Fluorocarbon Rubber) seals compatible with diverse media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection, wiring options include Lead Wire or DIN Connector configurations.
**Category**: Fluid Solenoid Valve | **Brand**: AirTAC | **Series**: 2KWL
AirTAC 2KWL Fluid Solenoid Valve 2KWL03008EI Technical Details
- Model: 2KWL03008EI
- Type: 2-position 3-way normally closed (direct-acting)
- Port configuration: IN/OUT/EXH (3 ports)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure range: 0.05–1.0 MPa
- Max working pressure: 1.6 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC: 2.4W (24V), AC: 3.2VA (220V)
- Flow coefficient (Cv): 0.14
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: FKM (Viton®) standard, EPDM/NBR optional
- Body material: Anodized aluminum alloy
- Operating temperature: -5℃ to 80℃ (with FKM seals)
- Protection class: IP67 (dustproof & waterproof)
- Electrical connection: DIN43650 Form A (standard), lead wire optional
- Weight: 280g ±5g
- Dimensions: 55mm(L) × 34mm(W) × 52mm(H)
High-precision fluid control valve with corrosion-resistant construction, designed for aggressive media handling. Features manual override capability and zero pressure differential operation. Equipped with copper-free aluminum construction for chemical compatibility. Requires 10μm filtration for optimal performance.
- Chemical dosing systems in water treatment plants
- Coolant flow control in CNC machining centers
- Medical fluid handling equipment
- Food-grade liquid dispensing systems (with EPDM seals)
- Hydraulic pilot stage control
- Laboratory analytical instrument fluidics
Critical notes:
- Install in horizontal orientation with coil facing upward
- Maximum allowable viscosity: 20 cSt
- Flush with clean fluid after chemical media use
- Minimum 200mm straight tubing required downstream
At 0.5MPa: Air consumption 450NL/min (ANR), Liquid flow rate 6.8L/min (water)
Leakage: ≤3 bubbles/min (air), ≤0.1mL/min (liquid)
Service life: 10 million cycles (clean air), 5 million cycles (liquid)
| Property | Property Value |
|---|---|
| sku | 2KWL03008EI |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC24V |
