Airtac 2KWL Fluid Solenoid Valve 2KWL03008FI
2. Wide pressure range adaptability, offering Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) models;
3. Compact design with minimized footprint, reduced weight, and tool-free modular assembly for easy maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (Fluorocarbon Rubber) seals compatible with diverse media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection, wiring options include Lead Wire or DIN Connector configurations.
**Category**: Fluid Solenoid Valve | **Brand**: AirTAC | **Series**: 2KWL
AirTAC 2KWL Fluid Solenoid Valve 2KWL03008FI Technical Specifications
- Model: 2KWL03008FI
- Type: 2-position, 3-way direct-acting solenoid valve
- Fluid compatibility: Air, water, light oils (ISO VG32 or lower)
- Port size: G1/8 (BSPP thread)
- Orifice diameter: 2.5mm
- Operating pressure: 0.05–1.0 MPa (vacuum to 10 bar)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 3.5W (DC), 5.5VA (AC)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: FKM (Viton®) for fluid resistance
- Body material: Brass with nickel plating
- Temperature range: -10℃ to 80℃ (fluid temperature)
- Ambient temperature: -5℃ to 50℃
- Protection rating: IP67 (dustproof and waterproof)
- Electrical connection: DIN43650 Form A connector
- Weight: 280g ±5g
- Dimensions: 60mm(L) × 35mm(W) × 45mm(H)
High-flow fluid control valve with zero differential pressure operation capability, featuring corrosion-resistant construction and bubble-tight shutoff. The 2KWL series employs a balanced poppet design for stable operation under pressure fluctuations. Includes manual override and surge suppression circuitry. Compatible with ISO 15407-1 standards for industrial durability.
- Coolant flow control in CNC machining centers
- Hydraulic pilot stage control systems
- Beverage dispensing equipment
- Medical fluid handling devices
- Solar thermal system circulation control
- Laboratory analytical instrument flow paths
Installation guidelines:
Mount in any orientation except coil-down position. Install a 10μm filter upstream.
For liquid applications, ensure complete drainage capability to prevent water hammer.
Allow 20mm clearance around coil for heat dissipation.
| Property | Property Value |
|---|---|
| sku | 2KWL03008FI |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
