Airtac 2KWL Fluid Solenoid Valve 2KWL05010AI
2. Wide pressure range adaptability, offering Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) models;
3. Compact design with minimized footprint, reduced weight, and tool-free modular assembly for easy maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (Fluorocarbon Rubber) seals compatible with diverse media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection, wiring options include Lead Wire or DIN Connector configurations.
**Category**: Fluid Solenoid Valve | **Brand**: AirTAC | **Series**: 2KWL
AirTAC 2KWL05010AI Fluid Solenoid Valve Specifications
- Model: 2KWL05010AI
- Type: 2-position, 3-way direct-acting (normally closed)
- Fluid compatibility: Air, water, light oils (ISO VG32 or lower)
- Port size: G1/8 (BSPP thread)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 1.8W (DC), 2.5VA (AC)
- Maximum flow rate: 750 L/min (Cv=1.2 at 0.5MPa)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: NBR (standard), optional FKM/Viton for aggressive fluids
- Temperature range: -5℃ to 80℃ (fluid/ambient)
- Protection rating: IP67 (coil), IP65 (valve body)
- Electrical connection: DIN43650 Form A connector
- Weight: 320g ±5% (including connector)
- Dimensions: 58mm(L) × 35mm(W) × 72mm(H) (excluding ports)
The 2KWL05010AI features a stainless steel plunger system and hardened brass body for chemical resistance in wet environments. Its zero-pressure differential start capability enables reliable operation in low-pressure systems. The dual-seal structure prevents cross-port leakage even under vibration. Compatible with pulse-width modulation (PWM) control for precise flow regulation.
- Coolant control in CNC machining centers
- Hydroponic nutrient dosing systems
- Medical sterilization equipment fluid circuits
- Beverage dispenser liquid control
- Industrial dishwasher water management
Installation guidelines:
Mount in any orientation except coil-down position. Use 10μm filtration for particulate control.
For liquid applications, install with flow direction arrow aligned. Allow 15mm clearance around coil
for heat dissipation. Apply thread sealant only on male ports (not NPT threads).
Voltage matching:
Ensure supply voltage matches coil specification within ±10% tolerance.
Continuous energization time should not exceed 85% duty cycle without cooling measures.
| Property | Property Value |
|---|---|
| sku | 2KWL05010AI |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
| Coil Voltage | AC220V |
