Airtac 2KWL Fluid Solenoid Valve 2KWL05010B
2. Wide pressure range adaptability, offering Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) models;
3. Compact design with minimized footprint, reduced weight, and tool-free modular assembly for easy maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (Fluorocarbon Rubber) seals compatible with diverse media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection, wiring options include Lead Wire or DIN Connector configurations.
**Category**: Fluid Solenoid Valve | **Brand**: AirTAC | **Series**: 2KWL
AirTAC 2KWL05010B Fluid Solenoid Valve Specifications
- Model: 2KWL05010B
- Type: 2-way normally closed direct-acting (liquid/gas compatible)
- Port size: G1/8 (ISO228-1 standard)
- Operating pressure: 0.02–1.0 MPa
- Fluid temperature range: 1℃ to 60℃
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC: 3.5W max, AC: 4.2VA max
- Response time: ≤15ms (open/close)
- Seal material: FKM (Viton®) for chemical resistance
- Body material: Brass with nickel plating
- Coil insulation class: Class F (155℃)
- Protection rating: IP67 (dust/water resistant)
- Weight: 300g ±5%
- Dimensions: 80mm(L) × 45mm(W) × 60mm(H)
- Flow coefficient (Cv): 0.8
- Port connection: Threaded (external tap for hose barb adapter optional)
- Electrical connection: DIN43650 Form A connector
High-flow solenoid valve with zero-pressure start capability, engineered for precise fluid control in aggressive media environments. Features anti-clogging optimized orifice design and dual-seal structure with redundant leak protection. Compatible with water, air, light oils, and neutral gases (N₂/CO₂). Includes manual override button for system debugging.
- Industrial coolant circulation systems
- Water treatment plant chemical dosing
- Beverage dispensing machine flow control
- Medical sterilization equipment steam regulation
- Hydroponic farming nutrient delivery
- Compressed air line management
Installation guidelines:
Mount with flow arrow aligned to media direction. For viscous fluids,
maintain ambient temperature ≥5℃ above fluid pour point. Install
upstream strainer (100 mesh minimum) when handling non-filtered media.
Allow 20mm clearance below valve for diaphragm maintenance.
| Property | Property Value |
|---|---|
| sku | 2KWL05010B |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
| Coil Voltage | DC24V |
