Airtac 2KWL Fluid Solenoid Valve 2KWL05010BI
2. Wide pressure range adaptability, offering Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) models;
3. Compact design with minimized footprint, reduced weight, and tool-free modular assembly for easy maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (Fluorocarbon Rubber) seals compatible with diverse media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection, wiring options include Lead Wire or DIN Connector configurations.
**Category**: Fluid Solenoid Valve | **Brand**: AirTAC | **Series**: 2KWL
AirTAC 2KWL05010BI Fluid Solenoid Valve Technical Details
- Model: 2KWL05010BI
- Type: 2-position 2-way normally closed (direct-acting)
- Port size: G1/2" (BSPP thread)
- Operating pressure: 0.05–1.0 MPa
- Fluid temperature range: -5℃ to 80℃
- Voltage options: DC12V (±10%), DC24V (±10%)
- Coil insulation class: Class F (155℃)
- Body material: Brass CW617N (electroless nickel plated)
- Seal material: FKM fluorocarbon rubber
- Protection rating: IP67 (coil), IP65 (valve body)
- Response time: ≤15ms (open/close)
- Flow coefficient (Cv): 2.4 (Kv=2.08)
- Weight: 680g ±5% (including coil)
- Dimensions: 105mm(L) × 50mm(W) × 75mm(H)
- Port spacing: 35mm (center-to-center)
High-flow fluid control valve with chemical-resistant seals, featuring zero differential pressure operation capability. The brass body with multi-layer plating ensures corrosion resistance in humid environments. Includes manual override and surge protection diode. Compatible with water, light oils, and air (lubricated or non-lubricated).
- Coolant control in CNC machining centers
- Chemical dosing systems (pH adjustment, disinfectant injection)
- Water treatment plant valve clusters
- Hydroponic irrigation control
- Medical equipment sterilization lines
- Beverage filling machine liquid control
Installation guidelines:
Mount with inlet port (P) facing downward in vertical orientation.
Install 100-mesh filter upstream. Maximum allowable pipe vibration:
4.9m/s². For continuous operation, maintain fluid viscosity below 20cSt.
| Property | Property Value |
|---|---|
| sku | 2KWL05010BI |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
| Coil Voltage | DC24V |
