Airtac 2KWL Fluid Solenoid Valve 2KWL05010E
2. Wide pressure range adaptability, offering Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) models;
3. Compact design with minimized footprint, reduced weight, and tool-free modular assembly for easy maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (Fluorocarbon Rubber) seals compatible with diverse media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection, wiring options include Lead Wire or DIN Connector configurations.
**Category**: Fluid Solenoid Valve | **Brand**: AirTAC | **Series**: 2KWL
AirTAC 2KWL05010E Fluid Solenoid Valve Technical Details
- Model: 2KWL05010E
- Type: 2-position, 2-way normally closed (direct-acting)
- Port size: G1/8 (BSPP thread)
- Fluid compatibility: Air, water, light oils (ISO VG32 or below)
- Pressure range: 0.02–1.0 MPa (vacuum to 145 PSI)
- Flow rate: 450 L/min (at 0.5 MPa pressure drop)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC: 2.5W max | AC: 3.5VA max
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Weight: 298g ±5g (with connectors)
- Dimensions: 65mm(L) × 50mm(W) × 80mm(H) (excluding fittings)
- Seal materials: Main seal - FKM (Viton®), secondary seals - EPDM
- Temperature range: -10℃ to 80℃ (fluid/media temp)
- Ambient temperature: -20℃ to 60℃
- Protection class: IP67 (NEMA 4X equivalent)
- Housing material: Reinforced PBT with UL94 V-0 rating
High-flow fluid control valve featuring corrosion-resistant construction and bubble-tight shutoff. The dual-seal design prevents cross-contamination between media and electrical components. Optimized flow path geometry reduces turbulence by 40% compared to standard models. Requires 25μm filtration upstream.
- Industrial cleaning equipment fluid control systems
- Medical device sterilization line liquid routing
- Reverse osmosis water treatment plants
- Food processing machinery (compatible with NSF-H1 lubricants)
- Chemical dosing systems with mild solvents
Installation guidelines:
Mount in horizontal orientation with coil facing upward. Install bypass valve for systems requiring manual override.
Maximum permissible viscosity: 32mm²/s. Cycle life ≥5 million operations (at rated conditions).
| Property | Property Value |
|---|---|
| sku | 2KWL05010E |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
| Coil Voltage | AC24V |
