Airtac 2KWL Fluid Solenoid Valve 2KWL05010EI
2. Wide pressure range adaptability, offering Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) models;
3. Compact design with minimized footprint, reduced weight, and tool-free modular assembly for easy maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (Fluorocarbon Rubber) seals compatible with diverse media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection, wiring options include Lead Wire or DIN Connector configurations.
**Category**: Fluid Solenoid Valve | **Brand**: AirTAC | **Series**: 2KWL
AirTAC 2KWL05010EI Fluid Solenoid Valve Specifications
- Model: 2KWL05010EI
- Type: 2-position, 3-way normally closed (direct-acting)
- Port size: G1/8 (BSPP thread)
- Operating pressure: 0.02–0.8 MPa
- Fluid compatibility: Air, water, light oils (ISO VG32 or below)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 700 L/min (ANR at 0.5MPa)
- Response time: ≤15ms (at 20℃)
- Seal material: FKM (Viton® equivalent) for chemical resistance
- Temperature range: -5℃ to 80℃ (non-freezing conditions)
- Protection rating: IP67 (dustproof and waterproof immersion up to 1m)
- Electrical connection: DIN43650 Form A connector
- Weight: 320g ±5% (including connector)
- Dimensions: 65mm(L) × 42mm(W) × 55mm(H) (excluding fittings)
High-flow compact solenoid valve with triple-seal structure, featuring brass body with electroless nickel plating for corrosion protection. Optimized for liquid and air switching in high-cycle applications (100 million operations design life). Includes manual override and status LED indicator (red). Requires 25μm filtration for liquid applications.
- Coolant control in CNC machining centers
- Hydraulic system pilot controls
- Beverage dispensing systems
- Semiconductor wafer cleaning equipment
- Mobile hydraulic platforms
Installation guidance:
Mount horizontally with flow arrow aligned. Use vibration-damping brackets
in mobile applications. For liquid use, install downstream filter (10μm)
and perform 30-sec air purge after maintenance.
| Property | Property Value |
|---|---|
| sku | 2KWL05010EI |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
| Coil Voltage | AC24V |
