Airtac 2KWX Fluid Solenoid Valve 2KWX03006E
2. Wide pressure range adaptability – options include Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free assembly/disassembly capability;
4. Brass valve body construction with Class B thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon consultation with our technical department;
5. IP65-rated coil protection, available in direct lead wire or DIN connector wiring configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWX Series
AirTAC 2KWX03006E Fluid Solenoid Valve Specifications
- Model: 2KWX03006E
- Type: 2-position, 3-way direct-acting (fluid control)
- Port size: G1/8 (BSPP thread)
- Operating pressure: 0.05–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC24V (±15%), AC110V (±10%), AC220V (±10%)
- Fluid temperature range: -5℃ to 80℃
- Ambient temperature range: -20℃ to 50℃
- Flow coefficient (Cv): 0.45
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Power consumption: 1.8W (DC), 2.2VA (AC)
- Seal material: FKM (Viton) standard (EPDM optional)
- Body material: Brass with nickel plating
- Protection rating: IP67 (coil assembly)
- Electrical connection: DIN43650 Form A
- Weight: 280g ±5g
- Dimensions: 60mm(L) × 42mm(W) × 48mm(H) (excluding connectors)
High-flow fluid control valve with direct-acting mechanism for precise liquid/gas regulation. Features corrosion-resistant brass construction and IP67-rated coil protection. Compatible with water, light oils, and compressed air. Requires 25μm filtration (40μm max particle size). Includes manual override capability for system diagnostics.
- Industrial water treatment systems
- Chemical dosing equipment
- Beverage dispensing machines
- Coolant control in CNC machining centers
- Hydroponic irrigation systems
- Medical sterilization devices
Installation guidelines:
Mount horizontally with fluid flow direction matching body arrow indicator.
Use PTFE thread sealant on ports. Allow 50mm clearance below coil for heat dissipation.
Maximum 85% duty cycle recommended for continuous operation.
| Property | Property Value |
|---|---|
| sku | 2KWX03006E |
| Port Size | PT1/8 |
| Flow Aperture | 1.5mm |
| Coil Voltage | AC24V |
