Airtac 2L Solenoid Valve 2L03006BI
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L Series Solenoid Valve 2L03006BI Technical Specifications
- Model: 2L03006BI
- Type: 5/2-way double solenoid operated (bi-stable)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC12V, DC24V, AC110V(50/60Hz), AC220V(50/60Hz)
- Weight: 0.65 kg ±5%
- Dimensions: 110mm(L) × 50mm(W) × 50mm(H)
- Body material: Aluminum alloy (anodized)
- Seal material: NBR (Nitrile) standard, optional Viton
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Flow capacity: 850 l/min (Cv=1.3 at 0.5MPa)
- Response time: ≤25ms (at rated voltage)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Protection rating: IP65 (coil assembly)
- Fluid compatibility: Compressed air (40μm filtered, lubricated or non-lubricated)
High-performance 5-port directional control valve featuring low power consumption and dual manual override. The optimized flow path design ensures minimal pressure drop, making it ideal for high-speed pneumatic systems. Features gold-plated terminals for corrosion resistance and integrated surge protection circuitry. Requires ISO 8573-1 class 3 compressed air.
- Automated assembly line tooling changers
- Rotary actuator control in packaging machinery
- Clamping systems for CNC machining centers
- Material handling robots (SCARA/Delta types)
- Cleanroom-compatible production equipment
- Plastic injection molding machine sequences
Installation guidelines:
Mount in vibration-free environment using M4 screws (max torque 1.2N·m).
Maintain 20mm clearance around valve for heat dissipation.
Use copper-free lubricants if air line contains oil mist.
| Property | Property Value |
|---|---|
| sku | 2L03006BI |
| Port Size | PT1/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC24V |
